American Control Electronics DCH401-5

Артикул: DCH401-5
Изготовитель: American Control Electronics
✅ В наличии
ЗАКАЗАТЬ ЗАКАЗАТЬ

Технические характеристики DCH401-5

Раздел
Постоянный ток
Подраздел
American Control Electronics
Вес
  • Manufacturer Part Number: DCH401-5
  • Manufacturer: American Control Electronics
  • Product Series: DCH
  • Family Series: American Control Electronics Drives, DCH Series
  • Description: 4Q HLV Chassis 12/24V 5
  • AC Voltage: 115 VAC, 230 VAC
  • Output Armature Voltage (DC): 0-12 VDC, 0-24 VDC
  • Max Armature Current (DC): 5 A
  • Nominal Input Voltage: 120 VAC, 240 VAC
  • Field Supply: None
  • Regen: Yes
  • Feedback: Armature
  • Operator Controls: Built In
  • Approvals: cUL, UL
  • Nominal Armature VDC: 12 VDC, 24 VDC
  • Net Weight: 1.34 lbs
  • Gross Weight: 1.34 lbs
В связи с текущей ситуацией и введенными санкциями, мы предоставляем всю информацию о стоимости наших товаров только по запросу.
Пожалуйста, свяжитесь с нами, и мы подготовим индивидуальное коммерческое предложение, учитывающее все ваши потребности и спецификации заказа.
Не нашли продукцию?

Если вы не нашли продукцию бренда American Control Electronics на нашем сайте, пожалуйста, свяжитесь с нами. Мы приложим все усилия, чтобы найти и предложить вам необходимый товар в кратчайшие сроки.

Заказать товар Заказать товар
American Control Electronics DCH401-5
Drives, DCH Series Item # DCH401-5 4Q HLV Chassis 12/24V 5 Regenerative Stopping/Reversing Current Limit and Power LEDs 1.05 Form Factor 1% Base Speed Regulation 80:1 Speed Range The DCH series combines an AC to DC switching power supply with a regenerative PWM drive, creating an all in one solution to applications requiring control of 12 or 24 VDC motors when only 115 or 230 VAC power is available. The microprocessor design allows the drive to be programmed for custom applications or routines to meet an OEMs needs. With an isolated front end, this series is compatible with a 0‑5 or 0‑10 VDC analog from any PLC and with it's 8‑bit on‑board microprocessor, the DCH can be customized in many applications to even replace a PLC.
