AMERICAN STAINLESS PUMPS CN8HDV
Артикул:
CN8HDV
Изготовитель:
AMERICAN STAINLESS PUMPS
✅ Под заказ
ЗАКАЗАТЬ
ЗАКАЗАТЬ
Технические характеристики CN8HDV
Раздел
Pumps
Подраздел
AMERICAN STAINLESS PUMPS
Вес
11.4525
-
Item: Centrifugal Pump
-
Best Efficiency Flow: 37 GPM
-
Best Efficiency Head: 62 ft.
-
Compatible Discharge Pipe Size: 1 1/2"
-
Compatible Intake Pipe Size: 1 1/2"
-
Connection Type: Barbed
-
Cord Length: 1 ft.
-
Cord Type: Amphenol Plug
-
Discharge Type: Barbed
-
Duty: Continuous
-
Duty Cycle: Continuous
-
Flow Rate @ 1 Ft Of Head (maximum): Not Applicable
-
Flow Rate @ 10 Ft Of Head (maximum): Not Applicable
-
Flow Rate @ 100 Ft Of Head (maximum): Not Applicable
-
Flow Rate @ 120 Ft Of Head (maximum): Not Applicable
-
Flow Rate @ 140 Ft Of Head (maximum): Not Applicable
-
Flow Rate @ 15 Ft Of Head (maximum): Not Applicable
-
Flow Rate @ 160 Ft Of Head (maximum): Not Applicable
-
Flow Rate @ 180 Ft Of Head (maximum): Not Applicable
-
Flow Rate @ 20 Ft Of Head (maximum): Not Applicable
-
Flow Rate @ 200 Ft Of Head (maximum): Not Applicable
-
Flow Rate @ 220 Ft Of Head (maximum): Not Applicable
-
Flow Rate @ 240 Ft Of Head (maximum): Not Applicable
-
Flow Rate @ 260 Ft Of Head (maximum): Not Applicable
-
Flow Rate @ 280 Ft Of Head (maximum): Not Applicable
-
Flow Rate @ 30 Ft Of Head (maximum): Not Applicable
-
Flow Rate @ 300 Ft Of Head (maximum): Not Applicable
-
Flow Rate @ 40 Ft Of Head (maximum): 53 GPM
-
Flow Rate @ 5 Ft Of Head (maximum): Not Applicable
-
Flow Rate @ 50 Ft Of Head (maximum): 35 GPM
-
Flow Rate @ 60 Ft Of Head (maximum): 14 GPM
-
Flow Rate @ 70 Ft Of Head (maximum): Not Applicable
-
Flow Rate @ 80 Ft Of Head (maximum): Not Applicable
-
Flow Rate @ 90 Ft Of Head (maximum): Not Applicable
-
For Use With Potable Systems: Yes
-
Frequency: 60 Hz
-
Height: 7 3/5"
-
Housing Material: Stainless Steel
-
Hp: 1 hp
-
Hp - Pumps: 1 hp
-
Impeller Material: Stainless Steel
-
Inlet Pressure: 10 psi
-
Installation Position: Horizontal
-
Intake Type: Barbed
-
Length: 10 4/5"
-
Max. Case Pressure: 50 psi
-
Max. Feet Of Head: 64 ft.
-
Max. Flow Rate @ 40 Ft.: 53 GPM
-
Max. Flow Rate @ 50 Ft.: 35 GPM
-
Max. Flow Rate @ 60 Ft.: 14 GPM
-
Max. Head: 64 ft.
-
Max. Solid Dia.: 0.27"
-
Max. Specific Gravity: 1
-
Max. Suction Lift: 24 ft.
-
Motor Enclosure Design: Totally Enclosed Fan Cooled
-
Motor Frame Designation: 56J
-
Mounting Orientation: Horizontal
-
Npshr: 10 psi
-
Outlet Type: Barbed
-
Overall Height: 7 3/5"
-
Overall Length: 10 4/5"
-
Overall Width: 6.7"
-
Overload Protection: Auto
-
Overload Thermal Protection: No
-
Phase: Single
-
Priming: Manual
-
Pump Housing Material: Stainless Steel
-
Required Net Positive Suction Head: 10 psi
-
Rpm: 3500 RPM
-
Rpm (maximum): 3500 RPM
-
Seal Material: Buna N, Carbon Ceramic
-
Self Priming: Manual
-
Series: FDP Series
-
Solid Diameter (maximum): 0.27"
-
Specific Gravity: 1
-
Specific Gravity (maximum): 1
-
Thermal Protection: No
-
Voltage: 115/230V AC
-
Wetted Material: Stainless Steel
-
Wetted Materials: Stainless Steel
-
Width: 6.7"
-
Height (cm): 19.3
-
Length (cm): 27.43
-
Width (cm): 17.02
