Appleton EDS175F23A

Артикул: EDS175F23A
Изготовитель: Appleton
✅ В наличии
ЗАКАЗАТЬ ЗАКАЗАТЬ

Технические характеристики EDS175F23A

Раздел
Приложенный
Подраздел
Appleton
Вес
  • Poles: 2
  • NEMA Rating: NEMA 3, NEMA 7, NEMA 9
  • Current Rating: 30 A
  • AC Voltage: 277 VAC
  • Operator Type: Front
  • Mounting: Wall
  • Fusible: No
  • Enclosure Composition: Metallic
  • Approvals: UL
  • Net Weight: 0 lbs
  • Gross Weight: 2.3 lbs
  • Description: Explosionproof Tumbler Switch Control Station, Type Dead End, Constructional Feature Explosionproof, Dust-Ignitionproof, Voltage Rating 120 to 277 VAC, Current Rating 30 Ampere, Contact Configuration 2-Pole, Operator Type Front Operated Lever, Box Type
  • Manufacturer Part Number: EDS175F23A
  • Manufacturer: Appleton
  • Product Series: Contender
  • Family Series: Appleton Disconnect Switches, Contender Series
В связи с текущей ситуацией и введенными санкциями, мы предоставляем всю информацию о стоимости наших товаров только по запросу.
Пожалуйста, свяжитесь с нами, и мы подготовим индивидуальное коммерческое предложение, учитывающее все ваши потребности и спецификации заказа.
Не нашли продукцию?

Если вы не нашли продукцию бренда Appleton на нашем сайте, пожалуйста, свяжитесь с нами. Мы приложим все усилия, чтобы найти и предложить вам необходимый товар в кратчайшие сроки.

Заказать товар Заказать товар
Appleton EDS175F23A
Disconnect Switches, Contender Series Item # EDS175F23A EFD CONTENDER N1 SERIES SNAP Explosionproof, Dust‑Ignitionproof. Ideal for installation in chemical and petrochemical plants, refineries and other process industries Enclosures have external mounting lugs for ease of mounting Smooth, rounded integral bushing in each hub protects conductor insulation Enclosures furnished with internal ground screw 20 Amp and 30 Amp units available for use with 120‑277 Vac Smooth ground mating surfaces assure flame‑tight joint between cover and mounting enclosure Stainless steel hex head cap screws for attaching cover to mounting enclosure Choice of front‑operating or side rocker arm handle; each may be locked in ON or OFF position Each handle has close‑tolerance threaded stainless steel shaft to meet Explosionproof requirements Enclosures furnished with internal ground screw Appleton explosionproof, dust‑ignitionproof Contender Series factory sealed front operated tumbler switches are designed to prevent arcing of enclosed switches in ignitable atmospheres during connect and disconnect operation of lighting and light power loads. They are designed for use in classified areas where ignitable vapors, gases or highly combustible dusts are present such as chemical and petrochemical plants, refineries and other process industries.
