Технические характеристики EDSC11271
Раздел
Пункты управления
Подраздел
Appleton
Вес
-
Manufacturer Part Number: EDSC11271
-
Manufacturer: Appleton
-
Product Series: Contender
-
Family Series: Appleton Switches, Contender Series
-
Description: Selector Switch Control Station, Type Feed Through, Constructional Feature Explosionproof, Dust-Ignitionproof, Voltage Rating 600 VAC, Current Rating 10 Ampere, Operation Type Maintained, Contact Configuration 4NO-4NC, Number of Circuits 2, Number of
-
Total Number of Devices: 1
-
Number of Pushbuttons: 0
-
Number of Pilot Lights: 0
-
Illuminated: No
-
Contact Type: Maintained
-
Enclosure: Feed-Thru
-
Mounting: Panel Mount
-
Hub Size: 1/2 "
-
Number of Selector Switches: 1
-
Selector Positions: 2
-
Selector Type: Knob
-
Approvals: CSA, UL
-
Net Weight: 0 lbs
-
Gross Weight: 10.85 lbs
В связи с текущей ситуацией и введенными санкциями, мы предоставляем всю информацию о
стоимости наших товаров только по запросу.
Пожалуйста, свяжитесь с нами, и мы подготовим индивидуальное коммерческое предложение,
учитывающее все ваши потребности и спецификации заказа.
Не нашли продукцию?
Если вы не нашли продукцию бренда Appleton на нашем сайте, пожалуйста, свяжитесь с нами. Мы приложим все усилия, чтобы найти и предложить вам необходимый товар в кратчайшие сроки.
Заказать товар
Заказать товар
Appleton EDSC11271
Switches, Contender Series
Item #
EDSC11271
2POS 1-UNIV SEL SW. STA-FS
Explosionproof, Dust‑Ignitionproof. Ideal for installation in chemical and petrochemical plants, refineries and other process industries
Enclosures have external mounting lugs for ease of mounting
Smooth, rounded integral bushing in each hub protects conductor insulation
Enclosures furnished with internal ground screw
20 Amp and 30 Amp units available for use with 120‑277 Vac
Smooth ground mating surfaces assure flame‑tight joint between cover and mounting enclosure
Stainless steel hex head cap screws for attaching cover to mounting enclosure
Choice of front‑operating or side rocker arm handle; each may be locked in ON or OFF position
Each handle has close‑tolerance threaded stainless steel shaft to meet Explosionproof requirements
Enclosures furnished with internal ground screw
Appleton explosionproof, dust‑ignitionproof Contender Series factory sealed front operated tumbler switches are designed to prevent arcing of enclosed switches in ignitable atmospheres during connect and disconnect operation of lighting and light power loads. They are designed for use in classified areas where ignitable vapors, gases or highly combustible dusts are present such as chemical and petrochemical plants, refineries and other process industries.
