Технические характеристики GRAC0001
Раздел
Медиаконвертеры
Подраздел
Red Lion
Вес
-
Description: Graphite Edge Controller
-
Total Number of Ports: 8
-
Primary Port Style: RJ-45
-
Primary Port Standard: 100Base-TX, 10Base-T
-
Voltage: 10-30 VDC
-
Nominal Voltage: 12 VDC, 24 VDC
-
Enclosure Composition: Aluminum
-
Mounting: DIN Rail, Panel
-
Operating Temperature: -40-158 °F
-
Approvals: CE, cULus
-
Net Weight: 2.3 lbs
-
Gross Weight: 3.55 lbs
-
Manufacturer Part Number: GRAC0001
-
Manufacturer: Red Lion
-
Product Series: Graphite Edge Controller
-
Family Series: Red Lion Media Converters, Graphite Edge Controller Series
В связи с текущей ситуацией и введенными санкциями, мы предоставляем всю информацию о
стоимости наших товаров только по запросу.
Пожалуйста, свяжитесь с нами, и мы подготовим индивидуальное коммерческое предложение,
учитывающее все ваши потребности и спецификации заказа.
Не нашли продукцию?
Если вы не нашли продукцию бренда Red Lion на нашем сайте, пожалуйста, свяжитесь с нами. Мы приложим все усилия, чтобы найти и предложить вам необходимый товар в кратчайшие сроки.
Заказать товар
Заказать товар
Red Lion GRAC0001
Media Converters, Graphite Edge Controller Series
Item #
GRAC0001
Graphite Edge Controller
INDUSTRY APPLICATIONS:
Factory Automation
Oil & Gas
Power & Utilities
Water/Wastewater
Transportation
Industrial Internet of Things (IIoT)
PRODUCT HIGHLIGHTS:
Industry‑Standard Control Language Support
Protocol Conversion of over 300 Drivers
Support up to 18 Simultaneous Protocol Conversions
Web Server For Data Visualization
Real‑Time Data Logging To Sd Card Or Via Ftp
Rugged Construction For Extreme Protection
Wide Operating Temperature Range
Scalable Modules & Expansion Options
Syncs Data Logs To Ftp Servers And Microsoft Sql Server
Provides Email And Sms Text Message Alerts (Sms Requires Gmhspa00 Module)
Configured Using Crimson 3 Software With Crimson Control
3 Fully Isolated Serial Communication Ports (1 Rs232 And 2 Rs422/485)
2 10 Base T/100 Base‑Tx Ethernet Connections Can Connect To An Unlimited Number Of Devices Via Ten Protocols Simultaneously
Integrated Graphite Rack Expansion Port,Add Up To 4 Gexrack2 3 Port Expansion Racks
Cast Aluminum Case Construction Supports Din Rail And Panel Mount
The Graphite Edge Controller is designed to remotely connect, monitor and control equipment in process applications. At the core of the product is Crimson 3.0 featuring an embedded IEC61131 controlengine, that can be configured via Ladder, Function Block, Structured Text, and Instruction List. Additionally, the Graphite Edge Controller is optimized for multi‑vendor environments with powerful protocol conversion, built‑in data logging and a virtual operator interface for remotely viewing equipment and processes.
The Edge Controller can be expanded to meet almost any application requirement through the use of plug‑in digital and analog I/O modules that leverage the Graphite Expansion Racks. The integrated rack port supports 4 GEXRACK2 bases (12 modules). An additional 12 modules can be added using the USB host port (GEXRACK1, 3 GEXRACK2).
Red Lion's industry leading protocol library offers access to over 300 drivers including PLCs, drives, cameras, bar code readers and many other devices providing easy data mapping to PLCs, PCs, and SCADA Systems. In addition, the Edge Controller can convert over 13 protocols simultaneously, seamlessly connecting and communicating with disparate devices. Graphite Edge Controllers offer numerous communication ports including high‑speed RS‑232/485 and 10/100BaseT(X) Ethernet ports. Additionally, the Edge Controller features built‑in USB host ports for fast downloads of configuration files and access to trending and data logging information.
Eliminate the need for external protocol converters and use an Edge Controller to connect and control to all your devices. The Graphite Edge Controller can be programmed with Red Lion's Crimson 3.0 software using a simple drag and drop interface to configure data tags, virtual displays, protocol conversion and data logging in minutes. Embedded in Crimson 3.0 software platform is the IEC 61131 control engine, Crimson Control which can be written in 4 programming languages including Ladder, Function Block, Structured Text, and Instruction List. The controller comes with Crimson Control functionality.
