Технические характеристики PN-580137
Раздел
Освещение
Подраздел
Sprecher + Schuh
Вес
-
Manufacturer Part Number: PN-580137
-
Manufacturer: Sprecher + Schuh
-
Product Series: CAVL7
-
Family Series: Sprecher + Schuh Contactors, CAVL7 Series
-
Description: CONTACTOR 60A-E UL 4NO 220VAC
-
Nominal Coil Voltage: 208 VAC, 240 VAC
-
Coil Voltage: 220 VAC
-
Coil Type: Mechanical
-
Poles: 4NO
-
Auxiliary Contact: None
-
Termination: Screw
-
Current Rating: 60 A
-
Enclosure: Yes
-
Approvals: cULus
-
Net Weight: 0 lbs
-
Gross Weight: 0 lbs
В связи с текущей ситуацией и введенными санкциями, мы предоставляем всю информацию о
стоимости наших товаров только по запросу.
Пожалуйста, свяжитесь с нами, и мы подготовим индивидуальное коммерческое предложение,
учитывающее все ваши потребности и спецификации заказа.
Не нашли продукцию?
Если вы не нашли продукцию бренда Sprecher + Schuh на нашем сайте, пожалуйста, свяжитесь с нами. Мы приложим все усилия, чтобы найти и предложить вам необходимый товар в кратчайшие сроки.
Заказать товар
Заказать товар
Sprecher + Schuh PN-580137
Contactors, CAVL7 Series
Item #
CAVL7-60-M40-220-L10
CONTACTOR 60A-E UL 4NO 220VAC
Compact Contactors for North American Lighting Applications
Sprecher + Schuh CAL7 and CAVL7 contactors can be used to control a wide variety of lighting loads. These contactors are well suited to handle the high inrush currents typical of this application as well as other non-motor (resistive) loads.
Tungsten Filament Lamps
• General purpose incandescent
• Special purpose incandescent
• Infrared
• Sodium Iodine
Discharge Lamps (with Ballast)
• Fluorescent lamps
• Mercury vapor
• High/low pressure sodium
• Quartz
• Halogen metal-vapor
Mixed Light Lamps
In Application
The tungsten filaments of incandescent lamps have a very low ohmic resistance when cold. As a result, the closing current is very high but also very short.
The closing current of discharge lamps (lighting with ballast) is highly inductive (due to series-connected transformers or chokes), and its duration depends on the lamp type.
